http://www.suzukicycles.org
Suzuki
GSF400 Bandit, 89-97

GSX-R400J  / FJ, GK73a,88, 59hp
GSX-R400rK and FK, GK73a, 89 59hp
(any additions or corrections to the above information, click here)
I still don't know about the 97+ models
 aprox. 50 True Rear Wheel HP

http://www.suzukicycles.org

Congratulations!

Ron Gilbert - Mount Holly, NJ

#1 Lightweight Sportbike Mid Atlantic Region
#2 Lightweight Superbike Mid Atlantic Region
#3 GT-3 Mid Atlantic Region

Carb Recalibration Kits and Extended Fuel Screws



Long Boy Fuel Screw Set

pn: 5020m

$89.95
 with 4 new screws, springs, washers and o-rings

1. Choose your shipping method

2.

"Long Boy"
Finger adj. extended Fuel Screw
Kit

Frustrated with trying to find an "almost 90 degree"  screwdriver to fine adjust your fuel screws for best idle and cruise?
Use Factory Pro's new "finger adjustable" fuel screws to adjust fuel screws for best throttle response. Traveling to high altitude? It's easy to lean out the lowend temporarily.

Make your life easier.


Installation:
Remove old short stock fuel screw, old o-ring, old washer and old spring. The o-ring might be stuck in the carb, so, take a light and make sure it's really out (if it didn't come out with the screw or you can't find it after you took out the screw)
Use a small bent wire to pull it out if it doesn't drop out. Keep the old parts for "spares".


#5020m fuel screw assembly comes with:
4 Long Boy fuel screws
 4 new o-rings
4 new washers
4 new springs



American Flags

T Jason Stanley Bandit 400

'95 GSXR 750 forks, rear sets, passenger rear sets

'94 RF 900 Swing arm and wheel

Fox Shock by Thor Suspension
Powder coated frame

Every seal and bearing replaced

Scotts Dampener and custom bracket



CRB-S41-1.0    $139.95
1. Choose your shipping method
2.

CRB-S41-1.0 + 4 Long Boy Fuel Screws
$209.90 regular price
Combo Pack - Save almost $20
$199.95

1. Choose your shipping method
2.


Standard drop-in carb kit

Adds more low-end / midrange, if the proper main jet is selected, more top-end power. Easy to install and tune - no slide drilling!

Note!
We have a kit that works from 89 to at least 1993.
we do not know if the kit fits the 94 to 97 models.
If you do know, email us.

 American Flags


  June 2013

The jet kit is in and it's running beautifully, can't believe the difference it's made!

Thanks for all the help


year model 1991 Bandit
Be
n Jansen
B
risbane, Queensland
Australia


CRB-S41-3.0  $139.95
1. Choose your shipping method
2.
American Flags



Config 30 carb kit

For the best top-end power. Good low-end and midrange. Requires removal of stock airbox and running BMC 3092 or K&N or equivalent individual air filters. Otherwise, it is a drop-in kit. Low-end response is as good as, if not better than the 1.0 kit with the stock airbox.
Uses 54mm bellmouth air filters.

Ignition Advance Kit  not available
Shift Improvement Kit



SHFT-SUZ-3   $39.95
1. Choose your shipping method
2.
American Flags



Our original Shift kit to improve shifting



The famous "spring and a gasket kit".
Includes new Factory Pro shift spring. Slightly stronger - making shifts quicker and best of all, almost eliminating missed shifts - regardless of how quickly you shift!



The oil pan gasket is for the 600/750 and 1100 - and am not sure if it is the same gasket as the 400. If you know, please email us. Thanks!




Note! These shift kits won't fix a broken transmission. If you have a bent shift fork and worn second gear "dogs" that pop out of gear at full throttle and higher rpm, you'll have to pull the engine, split the engine cases and replace second gear, the gear it mates with and the corresponding shift fork, gaskets and clips, shims and seals.



SHFT-PRO-SUZ-3   $139.95

1. Choose your shipping method
2.

American Flags



Trans Detent Arm Kit

The BEST kit.

Factory Pro can create a Pro Shift Kit (our late style microbearing detent arm AND heavier shift spring). On the Bandit / GSXR 400. The Pro Kit shifts even quicker than the above standard kit.
this kit, like the regular shift kit also requires that you access the oil pan (meaning, you have to remove the exhaust system, too.)
The oil pan gasket is for the 600/750 and 1100 - and am not sure if it is the same gasket as the 400. If you know, please email us. Thanks!



Note! These shift kits won't fix a broken transmission. If you have a bent shift fork and worn second gear "dogs" that pop out of gear at full throttle and higher rpm, you'll have to pull the engine, split the engine cases and replace second gear, the gear it mates with and the corresponding shift fork, gaskets and clips, shims and seals.


Carb Setting Tools

TL-float height gauge   $59.95

1. Choose your shipping method
2.

Made in Japan
The only way to accurately measure float heights. Works on nearly every carburetor.

In production for over 50 years.




Links

www.banditalley.com

www.gsxr400.com

www.400greybike.co.uk

Thanks to Jay Kovach for the info!!

Jay has Bandit / gsxr 400 442cc and 465cc kits for sale.
jbird474k@hotmail.com



Gallery - gsxr400, Bandit 400: Submit your bike's "best side!



Darren Leong wrote:

gk76a gsxr400 1990 sp model

The bike currently runs stainless headers, k5 rear shock and derestricted cdi unit with ignition advance as well.
July 25, 2006


David Hine's 400's best side


SCHMIGGY6@aol.com wrote:

I HAVE TWO QUESTIONS:
FIRST, I HAVE A 94 RF900R WITH A V&H SS2R SLIP-ON AND A K&N FILTER, AS WELL AS A STAGE I KIT. THE BIKE RUNS GREAT AND I WANT TO KNOW IF AN IGNITION ADVANCE WOULD DO ME ANY GOOD (WHAT WILL ONE DO?) ALSO DO YOU HAVE ANY DYNO
INFO ON A RF900?
SECOND, MY GIRLFRIEND HAS A 93 BANDIT 400 THAT HAS ALWAYS HAD POOR CARBURETION. WE ARE CONSIDERING A STAGE I KIT AND POSSIBLY A NEW PIPE/FILTER/ADVANCE COMBINATION AS WELL. DO YOU HAVE ANY DYNO INFO ON THIS BIKE AND HAS IT BEEN YOUR EXPERIENCE THAT THESE MACHINES HAVE SUCH POOR JETTING FROM THE FACTORY?
THANKS , AND GREAT WEB SITE!!!!!!!!!!
SCHMIGGY6@AOL.COM


The 400 Bandit?

Part of the problem is, like ALL of the 93-95ish watercooled Suzuki's, that it's got a very low temperature coolant thermostat ~170f, or so. Makes them seem to run lean and not idle well when the fuel screws are set for best idle after a good ride. Install a higher temp thermostat from, perhaps a cbr600f3. We use ~190f  thermostat, which is a bit higher than the f3, but 190f is where the engine runs the best and makes the best power. Either way, changing the thermostat is mandatory. Then you can tune the carbs for best throttle response with the kit.

It won't make the bike run too hot, it will just keep it from running too cool when just cruising around - like summer in foggy San Francisco - that is, south of the Golden Gate Bridge cause it's warmer to the north.

The CRB-S41-1.0 Carb Recal Kit will work much better - cleaner and more responsive everywhere. There is no ignition advance available.

If you were close to us, I would like to do a 1.7 style kit on the 400.









Absolutely NO carb parts sold in California.

New and improved Suzuki Teka SFI  2

with new TPS display and "MMT" Memory Module Tuner

Finally - Quick, easy, cost effective Suzuki tuning with no expensive "add-on boxes"
Suzuki cruisers and sportbikes

Please click here for more info

Contact Factory Pro
M-F, 9am - 5pm, Pacific time, -7 or -8 GMT

800 869-0497
 USA and Canada

415 491-5920

parts information
 info@factorypro.com

EC997 dynamometer information
info@factorypro.com

Product Support /Tech SECTION
click here



Mailing / Shipping address:

Factory Pro
179 Paul Drive
San Rafael, CA 94903
USA

And most importantly
Restart back at the HOME page and click on the red box in the top left to find the bike that you want parts for...
restart at HOME page
